PRODUCT BRIEF

The Fan model tree grate, and its sister model the KIVA, are our more cost effective grating solutions, and the closest we come to making a utility only product.

Underlying its utilitarian appearance, you will still find all the hallmarks of an Urban Accessories hand crafted tree grate – crisp edges, excellent surface quality and overall attention to detail.

Worth noting, the Fan is available in an extremely broad range of shapes and sizes…

 Conforms to ADA Accessibility Guidelines

Square
|  3′  pdf   dwg  |  3′-6″  pdf   dwg  |  4′  pdf   dwg  |
|  4′-6″  pdf   dwg  |  5′  pdf   dwg  |  6′  pdf   dwg  |
|  8′  pdf   dwg  |

Round
|  3′  pdf   dwg  |  4′   pdf   dwg  |  5′    pdf   dwg  |
|  6′  pdf   dwg  |

Rectangle
| 2′ x 3′  pdf   dwg  | 3′ x 5′  pdf   dwg  |  3′ x 6′   pdf   dwg  |
|  4′ x 6′  pdf   dwg  |  4′ x 8′  pdf   dwg  |  5′ x 8′   pdf   dwg  |

Installation Frame Information
Material and Finish Options
Powder Coat Color Chart
Lightport Worksheet – Add uplighting to any tree grate
Generic CSI Specification

100% Recycled Grey Iron ǂ, per ASTM A48 class 35b
Ductile Iron, per ASTM A536, class 65-45-12
100% Recycled Aluminum, per ASTM B26
Silicon Bronze, per ASTM B26
Nickel Bronze, per ASTM B30

 Reycled Content and Origin of Materials Affadavit

Raw Natural Finish ǂ
Rust Conditioner – Grey and Ductile Iron Only – Additional Information
Polyester Powder Coat – Standard color options
Liquid Coat – Available upon request – Please provide paint color number, system number and manufacturer.
Brush – Aluminum, Bronze and Nickel Bronze Only
Polish –  Aluminum, Bronze and Nickel Bronze Only

ǂ Standard
