PRODUCT BRIEF

Designed in conjunction with the prominent landscape architecture firm Halvorson Design Partnership, the Boston design radiates permanence combined with classic metropolitan charm.

Notable installations include Newport Beach’s Fashion Island and the newly redesigned San Diego Embarcadero.

 Conforms to ADA Accessibility Guidelines

Square
|  2′  pdf   dwg  |  3′  pdf   dwg  |  3′-3″  pdf   dwg  |
|  4′  pdf   dwg  |  5′  pdf   dwg  |  6′  pdf   dwg  |
|  8′  pdf   dwg   |  10′  pdf   dwg  |

Round
|  3′-3″  pdf   dwg  |  9′  pdf   dwg  |

Rectangle
|  4′ x 6′  pdf   dwg  |  4′ x 6′ (2pc)  pdf   dwg  |
|  4′ x 8′  pdf   dwg  |  4′ x 9′  pdf   dwg  |
|  5′ x 8′  pdf   dwg  |

Installation Frame Information
Material and Finish Options
Powder Coat Color Chart
Lightport Worksheet – Add uplighting to any tree grate
Generic CSI Specification

100% Recycled Grey Iron ǂ, per ASTM A48 class 35b
Ductile Iron, per ASTM A536, class 65-45-12
100% Recycled Aluminum, per ASTM B26
Silicon Bronze, per ASTM B26
Nickel Bronze, per ASTM B30

 Reycled Content and Origin of Materials Affadavit

Raw Natural Finish ǂ
Rust Conditioner – Grey and Ductile Iron Only – Additional Information
Polyester Powder Coat – Standard color options
Liquid Coat – Available upon request – Please provide paint color number, system number and manufacturer.
Brush – Aluminum, Bronze and Nickel Bronze Only
Polish –  Aluminum, Bronze and Nickel Bronze Only

ǂ Standard
